Solar panel systems often require multiple roof penetrations for pipes and cables, making standard flashings unsuitable. The Master Flash Solar Multi-Port range is designed specifically for this challenge, with five ports in one unit to accommodate varied conduit and cable sizes while ensuring a watertight seal. Available with lead or aluminium bases for tiled and shingle roofs, or as the Solar Multi-Port MR for metal roofing, these flashings combine durable EPDM or high-temperature silicone sleeves with flexible bases that mould to different profiles.

Easy to install and built to withstand weather extremes, they’re the ideal solution for both residential and commercial solar installations.

Why do solar panel installations require special flashing?

Solar systems often need multiple cables and pipes (like electrical leads or cooling conduits) to pass through the roof.

Standard flashings only cater for a single penetration, whereas multi-port flashings such as the Master Flash Solar Multi-Port handle multiple entries efficiently while maintaining a watertight seal.

What is the difference between the Solar Multi-Port and Solar Multi-Port MR?

Solar Multi-Port: Features five ports in one unit—one central port for a larger pipe (up to 49 mm diameter) and four additional side ports for smaller pipes or cables (up to 9 mm and 20 mm). Available with either a lead or aluminium base.

Solar Multi-Port MR: Designed for metal roofs and includes five ports in the same configuration, with an aluminium base that conforms to metal panels. Available in EPDM (black or grey) or high-temperature silicone.

What materials are they made from, and why?

Both models use durable EPDM or high-temperature silicone sleeves for superior flexibility, UV, ozone, and weather resistance.

The different bases provide either robust traditional performance (lead) or a lightweight, environmentally safer alternative (aluminium).

Do they accommodate variations in pipe and cable sizes?

Yes.

Centre port fits 0–49 mm pipes.

Side ports accommodate 0–9 mm or 4–23 mm cables or pipes.
This versatility makes them ideal for modern solar setups with varied conduit and cable layouts.

Are they easy to install?

Absolutely. Their flexible bases can be moulded to most roof profiles, and the sleeve can be trimmed precisely to match each penetration.

Installation typically takes minutes, following a “measure, trim, slide, form, seal” process.

How do I choose between the two options?

Choose Solar Multi-Port (aluminium or lead base) if you’re working with residential or tiled roofing types.

Opt for Solar Multi-Port MR when installing on metal roofs—its base is specifically formed for these surfaces.

Are these flashings suitable for all roof types?

Solar Multi-Port with aluminium or lead base works well on shingles, cement or ceramic tiles, and other roof finishes.

Solar Multi-Port MR is engineered specifically for metal roof systems.

Can they handle roof movement and thermal expansion?

Yes. The EPDM or silicone sleeves are flexible and absorb vibrations, thermal expansion, and contraction, ensuring the seal remains intact over time.

Can they deal with extreme weather conditions?

Yes. The materials are designed for durability in a wide temperature range (continuous service at –55°C to +100°C for EPDM, and up to +225°C for silicone), and resist UV, ozone, and other weather stresses.

Are these flashings suitable for commercial as well as residential solar installations?

Definitely. Their robust design, multiple ports, and long-term durability make them well-suited for both residential photovoltaic setups and larger-scale commercial solar systems.
